Aoptke Cable Drop Cable – Reliable Last‑Mile FTTH Solution

Outdoor-Ready & Self-Supporting

Our drop cable features a figure‑8 flat structure with two parallel FRP (fiber-reinforced plastic) or steel wire strength members and an optional steel messenger wire. This design allows the cable to be self-supporting between poles or buildings, resisting wind or span-induced strain. Lightweight and compact, it simplifies aerial deployment and significantly cuts labor costs.

G.657A2 Bend-Insensitive Fiber

The heart of the cable is the G.657A2 single-mode fiber, renowned for its low bend sensitivity and robust optical performance.With a small minimum bend radius (~7.5 mm), it's ideal for tight routing scenarios—wall corners, distribution boxes, and indoor transitions—while maintaining compatibility with standard G.652.D systems.

UV & Flame Resistant LSZH Jacket

Encased in a black LSZH (Low Smoke Zero Halogen) sheath, the cable provides excellent UV protection, flame retardance, and environmental resilience.Rated for –40 °C to +70 °C, it resists moisture and sunlight and limits toxic smoke in the unlikely event of a fire—making it safer for public spaces.

Excellent Mechanical Strength

Designed to endure outdoor environments, the cable offers strong mechanical performance:

·Tensile Strength: ~600 N (short-term) / ~300 N (long-term).

·Crush Resistance: ~2200 N/100 mm (short-term) / ~1000 N/100 mm (long-term) .

·Bending Radius: ≥15× diameter (static), ≥30× diameter (dynamic).

These specs ensure reliable performance during installation and throughout its service life.

Easy Installation & Maintenance

Thanks to its flat, lightweight form and novel groove design, the Aoptke cable is easy to strip, splice, and terminate .This streamlines field operations and minimizes errors, accelerating projects and reducing operational costs.

Specifications at a Glance

Why Aoptke Cable Delivers Value

• ·Designed for last-mile aerial deployment, perfect for poles, buildings, and campus environments.



• ·Low-loss G.657A2 fiber ensures high reliability in tight installations.



• ·Robust mechanical specs reduce field damage and lifecycle costs.



• ·LSZH sheath enhances safety and compliance.



• ·Fast, clean installation thanks to lightweight, groove-friendly design.

  ---

onnect with Us Today

Want to explore how Aoptke Drop Cable can power your FTTH rollout? Contact us for:

• ·Free sample reels

• ·Full technical datasheets

• ·Competitive pricing

• ·On-site installation support

Aoptke Cable – delivering high-performance connectivity, every connection secured.
